Aruba 2930F 8G PoE+ 2SFP+ Layer 3 Switch, 125W PoE & 2x 10G SFP+ Uplinks (JL258A)
0,00 EGP
The Aruba 2930F 8G PoE+ switch (JL258A) features 8 Gigabit PoE+ ports (125W budget) and 2 ultra-fast 10G SFP+ uplinks with a 56 Gbps switching capacity. Outfitted with the ProVision ASIC, Layer 3 routing (OSPF/RIP), and VSF stacking, it delivers enterprise power in a compact form factor.
Description
The Aruba 2930F 8G PoE+ 2SFP+ Switch (JL258A) is a high-performance Layer 3 access switch engineered with 125W PoE+ power, dual 10-Gigabit SFP+ optical uplinks, and VSF stacking for space-constrained enterprise edge deployments.
Technical Specifications & Core Features
| Specification / Feature | Technical Details |
|---|---|
| Model / SKU | Aruba 2930F 8G PoE+ 2SFP+ (JL258A) |
| Downlink Ports | 8 × 10/100/1000 Mbps RJ45 Gigabit Ethernet PoE+ Ports |
| Uplink Interfaces | 2 × 1G / 10G SFP+ Dedicated High-Speed Optical Slots |
| PoE Power Budget | 125W Dedicated PoE+ Budget (802.3at / 802.3af Compliant) |
| Switching Bandwidth | 56 Gbps Wire-Speed Bandwidth |
| Throughput | 41.7 Mpps |
| Architecture Engine | Aruba ProVision ASIC with ARM Coretex A9 @ 1016 MHz |
| Layer 3 Routing | Access OSPF, Static IPv4/IPv6, RIPv1/v2/ng, Policy Routing (No Software Licensing Required) |
| Virtual Stacking | Virtual Switching Framework (VSF) Stacking Support |
| Security & Policy | Aruba ClearPass Integration, 802.1X, MACsec Readiness, Port Security, ACLs |
| Management Options | Aruba Central Cloud, Aruba AirWave, Full CLI, Web GUI, Out-of-Band Management Port |
| Form Factor | Compact 1U Rackmount / Desktop Enclosure with Internal Power Supply |
Package Contents
- Switch Unit: 1 × Aruba 2930F 8G PoE+ 2SFP+ Switch (JL258A)
- Power Cable: 1 × Regional AC Power Cable
- Mounting Hardware: 1 × Rack/Wall Mounting Kit and Rubber Feet
- Documentation: Quick Start Guide and Regulatory Pointer
Recommended Applications
- 10G Edge Aggregation: High-speed 10G fiber uplinks connecting remote office switches to campus cores.
- Compact Enterprise Branch Nodes: Supplying PoE+ power and Layer 3 routing in small IT closets.
- High-Performance AP Clusters: Powering multi-gigabit Wi-Fi 6 access points with low latency buffering.
- Secure Industrial & IoT Edges: ClearPass policy enforcement and dynamic role-based network segmentation.
