ProLink CAT6A S/FTP Patch Cord 3m LSZH White (PL-PC-S6A-3W)
0,00 EGP
ProLink CAT6A S/FTP Patch Cord 3m LSZH White (Model: PL-PC-S6A-3W) is a professional-grade Category 6A S/FTP Ethernet patch cord engineered for structured cabling systems. Measuring 3 meters in length, it provides reliable shielded connections between patch panels, network switches, routers, servers, and telecommunications outlets while supporting Ethernet applications operating up to 650 MHz. Its Low Smoke Zero Halogen (LSZH) jacket enhances fire safety, making it an ideal choice for enterprise LANs, commercial buildings, high-density data centers, and professional networking installations.
Description
ProLink CAT6A S/FTP Patch Cord 3m LSZH White (Model: PL-PC-S6A-3W) is a professional Category 6A S/FTP Ethernet patch cord designed for structured cabling systems. With a 3-meter cable length, this white shielded patch cord provides reliable connections between patch panels, network switches, routers, servers, and telecommunications outlets while supporting organized cable routing inside racks and network cabinets.
It supports Ethernet applications operating at frequencies up to 650 MHz and meets Category 6A Class E (650 MHz) requirements according to ISO/IEC 11801. Featuring a Low Smoke Zero Halogen (LSZH) jacket and an integrated wide-function strain relief boot, it is well suited for enterprise LANs, commercial office networks, data centers, and other professional networking environments.
Technical Specifications
| Component / Property | Technical Specification |
|---|---|
| Product Line | ProLink CAT6A S/FTP Patch Cord 3m LSZH White |
| Model / SKU | PL-PC-S6A-3W |
| Cable Length / Color | 3 Meters / White |
| Wiring Configuration | T568B Standard |
| Cable Type / Shielding | S/FTP (Shielded) |
| Conductor Gauge | AWG26/7 Stranded Conductor |
| Number of Pairs | 4 Pairs |
| Nominal Impedance | 100 Ohms |
| Operating Frequency | Up to 650 MHz |
| Category Compliance | Category 6A Class E (650 MHz) according to ISO/IEC 11801 |
| Outer Cable Diameter | Maximum 6.5 mm |
Mechanical Specifications
| Component / Material | Operational Rating / Property |
|---|---|
| Plug Housing Material | Polycarbonate |
| Contact Blade Material | Phosphor Bronze (CuSn6) |
| Contact Area Plating | 0.7 μm Selective Gold Plate |
| Connector Shield Material | Tin-Plated Brass |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| Interface Standard | Compliant with IEC 60603-7 |
| Operating Temperature | -10°C to +60°C |
| Integrated Cable Boot | Wide-Function Strain Relief |
Electrical Characteristics
| Electrical Parameter | Standard / Test Rating | Performance Value |
|---|---|---|
| Current Rating | Maximum @ 25°C | 1.5 Amps |
| Voltage Rating | Maximum Capacity | 150 VAC |
| Dielectric Withstanding Voltage | 1 Minute Test (60 Hz) | 1000 VAC |
| Insulation Resistance | Minimum Threshold | 650 MΩ |
Key Features
- Category 6A Performance: Supports Ethernet applications operating at frequencies up to 650 MHz and meets Category 6A Class E (650 MHz) requirements according to ISO/IEC 11801, delivering reliable performance for Gigabit and multi-gigabit Ethernet networks.
- LSZH Jacket: The Low Smoke Zero Halogen (LSZH) jacket helps reduce smoke and hazardous emissions during fire incidents, making it suitable for commercial buildings, enterprise networks, educational facilities, healthcare environments, and enclosed installations.
- Backward Compatibility: Backward compatible with existing Cat5e and Cat6 network installations, allowing gradual infrastructure upgrades while maintaining compatibility with structured cabling systems.
- Optimized Cable Management: The integrated wide-function strain relief boot helps protect the connector from cable stress while supporting cable identification, labeling, and organized cable management inside racks and network cabinets.
- Factory Tested: Each patch cord is individually tested and marked with a quality stamp to verify compliance with Category 6A performance requirements before shipment.
Compatibility & Recommended Applications
The PL-PC-S6A-3W is designed for Category 6A structured cabling systems and is backward compatible with Cat5e and Cat6 installations. It supports a wide range of networking equipment and is suitable for professional networking environments, including:
- RJ45 Ethernet interfaces
- Patch panels and telecommunications outlets
- Network switches, routers, and firewalls
- Servers and server rack interconnections
- Enterprise LAN infrastructure
- Commercial office structured cabling systems
- High-density data center patching
- Rack-to-rack network connections
- Gigabit and multi-gigabit Ethernet network installations
- Educational institutions and healthcare facilities
- Category 6A and backward-compatible Cat5e/Cat6 structured cabling systems
Quality Assurance
Manufactured using high-quality materials and in accordance with internationally recognized structured cabling standards, the ProLink CAT6A S/FTP Patch Cord 3m LSZH White is individually factory tested to verify electrical performance and Category 6A compliance. Featuring phosphor bronze contacts with 0.7 μm selective gold plating, an LSZH jacket, and compliance with IEC 60603-7, it provides dependable long-term performance for professional networking environments.
